Introduction about KingClima Evaporator Blower for EBM K3G097-AK34-65G02

The ebm papst k3g097-ak34-65 provided by KingClima is all original, and it is guaranteed that you can buy the best quality EBM evaporator blower at the most suitable price.

KingClima is the leading supplier of evaporator blower in China with best price and professional service! We have all kinds of evaporator blowers for OEM and aftermarket field.

Weight	2 kg
Fan size	97 mm
Impeller material	PA plastic UL94 HB (black)
Housing material	PP plastic (black)
Balancing grade according to DIN ISO 1940-1	G 2.5
Direction of rotation	Clockwise, viewed toward rotor
Degree of protection	IP24 KM
Insulation class	"B"
Moisture (F) / Environmental (H) protection class	F3-2
Max. permitted ambient temp. for motor (transport/storage)	+70 dgree
Min. permitted ambient temp. for motor (transport/storage)	-40 dgree
Installation position	Any
Condensation drainage holes	None, open rotor
Cooling hole/opening	On rotor side
Mode	S1
Motor bearing	Ball bearing
Life expectancy	40,000 h (typical)
Technical features	-Start at 85 °C (2 min) permitted
	- Load dump (58 V)
	- Motor current limitation
	- Soft start
	- Control input 0-10 VDC / PWM
	- Overvoltage detection
	- Thermal overload protection for electronics
	- Line undervoltage detection
EMC regulations	According to ECE R10 Rev. 3
Electrical hookup	With plug; Standby current less than 500 µA
Motor protection	Reverse polarity and locked-rotor protection
Approval	E1; EAC
Sound level	76 dB(A), sound power level according to ISO 13347
